Tuesday, October 24, 2017

Midi To Trig with selectable MIDI channel.

I combined the work of two great minds and made this midi to trigger interface with changeable midi channel.

http://www.notesandvolts.com and http://youthvulture.blogspot.com/2014/03/rhythm-ace-fr-2l-midi-retrofit-with.html




// ************************************************************************
// AUDUINO - MIDI Upgrade v1.1
// For Arduino NANO
//
// MIDI programming by Notes and Volts http://www.notesandvolts.com
//
// Tutorial - http://www.notesandvolts.com/2015/05/auduino-synth-midi.html
//
// ** Requires Arduino MIDI Library v4.2 or later **
//
// Based on the Auduino Synthesizer v5 by Peter Knight http://tinker.it
// ************************************************************************
// Version 1.0 - Initial release
// Version 1.1 - Fixed bug that caused note to hang with some DAWs
// ************************************************************************

#include <avr/io.h>
#include <avr/interrupt.h>
#include <MIDI.h> // Requires Arduino MIDI Library v4.2 or later

// *******************************************************************************
// If the DIP Switch option is installed - set dipSwitchInstalled to "true"
const bool dipSwitchInstalled = true;
// DIP Switch Setting = Channel (1=ON, 0=OFF)
// 0000 = 1   0001 = 2   0010 = 3   0011 = 4
// 0100 = 5   0101 = 6   0110 = 7   0111 = 8
// 1000 = 9   1001 = 10  1010 = 11  1011 = 12
// 1100 = 13  1101 = 14  1110 = 15  1111 = 16
//
// If DIP Switch is NOT installed - change dipSwitchInstalled to "false"
// If dipSwitchInstalled is set to false, the MIDI channel will be set
// to the value of MIDICHANNEL
#define MIDICHANNEL 1 // Can be a value from 1 to 16
// *******************************************************************************

MIDI_CREATE_DEFAULT_INSTANCE();

// DIP Switch Pins
#define DIP_SW1 9
#define DIP_SW2 10
#define DIP_SW3 11
#define DIP_SW4 12

#if defined(__AVR_ATmega8__)
//
// On old ATmega8 boards.
//    Output is on pin 11
//
#define LED_PIN       13
#define LED_PORT      PORTB
#define LED_BIT       5
#elif defined(__AVR_ATmega1280__)
//
// On the Arduino Mega
//    Output is on pin 3
//
#define LED_PIN       13
#define LED_PORT      PORTB
#define LED_BIT       7
#else
//
// For modern ATmega168 and ATmega328 boards
//    Output is on pin 3
//
#define LED_PIN       13
#define LED_PORT      PORTB
#define LED_BIT       5
#endif

#define TRIG1 2     // Trig1 set to Arduino Pin 2
#define TRIG2 3     // Trig2 set to Arduino Pin 3
#define TRIG3 4     // Trig3 set to Arduino Pin 4
#define TRIG4 5     // Trig4 set to Arduino Pin 5
#define TRIG5 6     // Trig5 set to Arduino Pin 6
#define TRIG6 7     // Trig6 set to Arduino Pin 7
#define TRIG7 8     // Trig7 set to Arduino Pin 8

int TIME = 5;        // Very short delay time to keep the loop snappy

void NoteOnMidi(byte channel, byte pitch, byte velocity){
  digitalWrite(TRIG1, LOW);    // All pins set to LOW, since
  digitalWrite(TRIG2, LOW);  // rising edge (HIGH to LOW).
  digitalWrite(TRIG3, LOW);
  digitalWrite(TRIG4, LOW);
  digitalWrite(TRIG5, LOW);
  digitalWrite(TRIG6, LOW);
  digitalWrite(TRIG7, LOW);


  if (velocity > 0){             // So midi devices that send note-on at zero
                                 // velocity for note-off don't double trigger.
    if (pitch == 60) {
      digitalWrite(TRIG1, HIGH);   // Looks for specific note numbers. If
      delay(TIME);               // they occur, rises from LOW to HIGH,
      digitalWrite(TRIG1, LOW);  // firing the trigger circuit, then
    }                            // goes back to LOW in anticipation of
    else if(pitch == 62) {
      digitalWrite(TRIG2, HIGH);
      delay(TIME);
      digitalWrite(TRIG2, LOW);
    }
       else if(pitch == 64) {
      digitalWrite(TRIG3, HIGH);
      delay(TIME);
      digitalWrite(TRIG3, LOW);
    }
    else if(pitch == 65) {
      digitalWrite(TRIG4, HIGH);
      delay(TIME);
      digitalWrite(TRIG4, LOW);
    }
    else if(pitch == 67) {
      digitalWrite(TRIG5, HIGH);
      delay(TIME);
      digitalWrite(TRIG5, LOW);
    }
    else if(pitch == 69) {
      digitalWrite(TRIG6, HIGH);
      delay(TIME);
      digitalWrite(TRIG6, LOW);
    }
    else if(pitch == 71) {
      digitalWrite(TRIG7, HIGH);
      delay(TIME);
      digitalWrite(TRIG7, LOW);

    }
  }
}




void setup() {
  if (dipSwitchInstalled) {
    pinMode(DIP_SW1, INPUT_PULLUP);
    pinMode(DIP_SW2, INPUT_PULLUP);
    pinMode(DIP_SW3, INPUT_PULLUP);
    pinMode(DIP_SW4, INPUT_PULLUP);
  }
  pinMode(LED_PIN, OUTPUT);
  pinMode(TRIG1, OUTPUT);
  pinMode(TRIG2, OUTPUT);
  pinMode(TRIG3, OUTPUT);
  pinMode(TRIG4, OUTPUT);
  pinMode(TRIG5, OUTPUT);
  pinMode(TRIG6, OUTPUT);
  pinMode(TRIG7, OUTPUT);

    if (dipSwitchInstalled) {
    MIDI.begin(DipSwitch());
  }
  else {
    MIDI.begin(MIDICHANNEL);
  }
  MIDI.setHandleNoteOn(NoteOnMidi);

}
byte DipSwitch() {
  byte value = 0;
  if (digitalRead(DIP_SW4) == LOW)
    value += 1;
  if (digitalRead(DIP_SW3) == LOW)
    value += 2;
  if (digitalRead(DIP_SW2) == LOW)
    value += 4;
  if (digitalRead(DIP_SW1) == LOW)
    value += 8;
  return (value + 1);
}


void loop(){
  MIDI.read();          // Tells Arduino to start listening for
}                       // midi info on the serial port

Friday, August 4, 2017

Fixing a broken Electro Harmonix slide potentiometer

I recently acquired a 1981 Electro Harmonix Graphic Fuzz with two broken sliders.



The Overdrive and the Vol sliders had both been broken off.

Here's what the broken overdrive pot looked like.



Luckily smallbear electronics sell drop in replacements!
The slide pots are:

Overdrive = 100k
Dynamics = 100k
Sustain = 100k
EQ pot 125–2000 Hz = 100k
4000 Hz = 10k
Vol = 10k

So I needed 1 100k and 1 10k potentiometer.

Here's what a brand new CTS 100k linear potentiometer looks like:


The only 10k CTS slider smallbear sells is reverse log and here's what that looks like:


I installed the 100k linear overdrive pot and it worked great. The 10k revLog for volume worked too, but since it was reverse logarithmic most of the change happened at the bottom of the slider. Not sure if the original is linear or logarithmic. But it was most definitely not reverse log.

Hoping they hadn't changed the insides of these CTS pots. I decided to just replace the lever part.
You open it by carefully bending these 4 tabs:

The new one:

and the old one:

Here's what the inside of the old one looked like:


Then you move the lever from the new pot to the old one. Luckily it fit perfectly:


Then you put the top part back on top of that.

And TADA!

A repaired CTS slide pot!

And here's what the pedal looks like now:


I replaced the old white slider tops with new ones from tayda for a uniform look.




Friday, February 3, 2017

808 Drum schematics.

Here are some schematics I've pulled out of the TR-808 schematics. I didn't do the bass drum, snare or hihat since ericarcher.net has already done a way better job than I could with that.
Inspired by him I've so far made veroboard versions of the bass drum, snare drum, the three toms and the cowbell.
I'll post those layouts once I'm done with layouts for all the sounds. Not sure why I'm posting this, but, eh, why not.
So, yeah, Here's something:


Handclap/Maracas:



The toms/congas use pink noise from the noise generator.
The snare uses white noise created by the same circuit.

High tom/conga:



Low tom/conga:



Mid tom/conga:



Rim shot/Claves:


Cymbal:



Cowbell:


These last two also uses a schmitt trigger. Look up the original schematic and you'll figure it out.

But it looks like this:




Friday, July 3, 2015

1968 Maestro Fuzz-Tone FZ-1 A







A friend of mine showed up with this thing the other day. I traded him some stuff for it and started researching.

The serial number is 37636 and the attack pot dates to the first week of 1968. (1376801). And since they made about a gazillion of these things I'm guessing that pot didn't stay in the factory for very long, so I'm going to assume this left the Kalamazoo factory in the earlier part of 1968.



A bunch of things on this pedal have been changed/lost/serviced.

First and most importantly* the knobs.

(*since looks really is the only thing that really matters.)

Since these pedals used the same type of knobs as the gibson guitars of the era I'm sadly assuming a previous owner put the original knobs up on ebay claiming they came from a 1968 SG Custom or something ridiculous. The same way it seems to be hard to find a 50's or 60's fender or gibson lap steel with it's original knobs. Or sometimes even pickups.

I've been trying to figure out what knobs this one would've had. I couldn't find any specific information about it anywhere. But from my research I feel somewhat confident in saying that this one probably had the gold reflector knobs. As that is what I've seen on all the others with similar serial numbers.

So my guess is that Gibson changed from the black reflector knobs to the gold ones in 1968 or late 1967. Again, I'm really not sure and I have no facts to back this up. Just some observations.

(I've also seen a couple of FZ's with the "witch hat" knobs. But it's hard to tell if they would be "original". Since those knobs nowadays are really hard to come by it would be strange for someone to waste them on a pedal, but oh well. Who cares?
I wouldn't be surprised if they just grabbed whatever knobs they had at the factory if they ran out of the ones they were supposed to use.)

Aaaaanyway.

Here are some more pictures of famous people using the FZ1a's predecessor the FZ1.








Black knobs: 1965-67?


Gold knobs: 1968?



Anyway, I don't know what I'm talking about.


Thursday, February 27, 2014

"Oktavgenerator"

Intressanta artiklar ur gamla nummer av Radio och television/Allt om elektronik.
Del 11:
"Oktavgenerator"
Ur Allt om elektronik nr 10 1986:




"Vindgenerator"

Intressanta artiklar ur gamla nummer av Radio och television/Allt om elektronik.
Del 10:
"Vindgenerator"
Ur Allt om elektronik nr 9 1982:


Wednesday, February 19, 2014

"Enstämmigt elektroniskt musikinstrument"

Intressanta artiklar ur gamla nummer av Radio och television.
Del 9:
"Enstämmigt elektroniskt musikinstrument"
Ur radio och television nr 10 Oktober 1963:
